Video Streaming Architecture: Netflix, Transcoding, and Edge CDNs
Architecture of a video streaming platform like Netflix or YouTube. Covers video chunking, DASH/HLS protocols, DAG transcoding pipelines, and CDN edge delivery.
Designing a video streaming system like YouTube, Netflix, or TikTok is fundamentally different from a standard web application. Standard apps transfer a few kilobytes of JSON data. Video platforms transfer Petabytes of continuous, high-bandwidth blob data globally without buffering.
1. Video Formats and Protocols
You cannot simply upload an MP4 file to a server and have millions of users download it simultaneously. If a user on a slow 3G connection tries to download a 4K video, it will buffer indefinitely.
Video Chunking
Videos are split into tiny chunks (e.g., 4 to 10 seconds long). Instead of downloading a massive 2GB file, the video player downloads hundreds of tiny 2MB files sequentially.
Adaptive Bitrate Streaming (ABR)
Modern video players (like Netflix's web player) continuously monitor your internet connection speed.
- If your connection is fast, the player requests the next 4-second chunk in 1080p.
- If you drive into a tunnel and your connection drops, the player instantly requests the next 4-second chunk in 360p to prevent the video from buffering.
This magic is powered by protocols like HLS (HTTP Live Streaming) by Apple and MPEG-DASH.
2. The Transcoding Pipeline (DAG)
When a creator uploads a raw 4K video to YouTube, it must be converted into multiple formats, resolutions, and bitrates to support every device in the world (from an iPhone 6 to a 4K Smart TV).
This requires a massive compute cluster to perform Video Transcoding.
graph TD
Upload[Raw Video File] --> Storage[(S3 Original Storage)]
Storage --> Dispatcher[Job Dispatcher Worker]
Dispatcher --> DAG[Directed Acyclic Graph Scheduler]
DAG --> T1[Transcode: 1080p MP4]
DAG --> T2[Transcode: 720p WebM]
DAG --> T3[Transcode: 360p iOS HLS]
DAG --> T4[Extract Audio: AAC]
DAG --> T5[Generate Thumbnails]
T1 --> Final[(S3 Processed Storage)]
T3 --> Final
Because video processing takes hours, the pipeline is modeled as a Directed Acyclic Graph (DAG). A DAG scheduler (like Apache Airflow) takes the original video, splits it into parallel jobs, and distributes those jobs across hundreds of worker servers. One server converts chunk 1 to 1080p, while another server converts chunk 2 to 720p simultaneously.
3. High-Level Delivery Architecture
Serving video out of a centralized database is a fatal architectural mistake. The bandwidth costs would bankrupt the company, and users on the other side of the planet would experience massive lag.
The Content Delivery Network (CDN)
100% of video delivery is handled by a CDN. A CDN is a global network of "Edge Servers". When Netflix releases a popular new show, they proactively push the video chunks to thousands of CDN servers located directly inside local Internet Service Providers (ISPs) all over the globe.
When a user in London clicks "Play", the video isn't streamed from Netflix headquarters in California. It is streamed from a physical server located a few miles away in London.
4. Metadata and Search Database
While the actual video files live in S3 and CDNs, the Metadata (Video Title, Description, View Count, Comments, Likes) lives in a standard database.
Because YouTube has billions of videos and trillions of views, a standard SQL database will quickly bottleneck on the "View Count" updates.
- Metadata DB: A highly sharded SQL database (like MySQL via Vitess) or a NoSQL database (like Cassandra) stores the video titles and user profiles.
- Search DB: Every video title and description is piped into Elasticsearch to provide instant full-text search capabilities when a user types in the search bar.
- View Counters: Updating a view count directly in the DB for every single view is too slow. View counts are aggregated in memory (using Redis or a streaming engine like Flink) and flushed to the database in batches every few minutes.
