Hierarchical Data: Traversing Binary Trees, BSTs, and Tries

Explore hierarchical structures, pre-order/in-order/post-order traversals, Binary Search Tree properties, self-balancing trees, and Tries.

byte team··14 min read·Updated Sep 20, 2025
Hierarchical Data: Traversing Binary Trees, BSTs, and Tries

Unlike arrays and linked lists, which store data sequentially in a flat line, Trees represent hierarchical, non-linear structures. They map perfectly to real-world systems like folder directories in an OS, the DOM tree in an HTML document, or the organizational chart of a company.

A Binary Tree is a specific type of tree where each node can have at most two child nodes, typically referred to as the left child and the right child.

Depth-First Tree Traversal Protocols

To search, clone, or process elements in a tree, you must visit all nodes. Because trees are non-linear, you can't just run a simple for loop. We rely on Depth-First Search (DFS) traversals.

There are three primary depth-first traversal patterns, defined entirely by when the algorithm processes the current node relative to its children:

       (1: Root)
       /       \
  (2: Left)  (3: Right)
  1. Pre-Order Traversal (Root -> Left -> Right):
    • Use Case: Used to clone a tree perfectly, or evaluate mathematical expression trees (Prefix notation).
  2. In-Order Traversal (Left -> Root -> Right):
    • Use Case: When run on a Binary Search Tree, this visits elements in perfectly sorted ascending order.
  3. Post-Order Traversal (Left -> Right -> Root):
    • Use Case: Used to safely delete nodes from memory (you must delete children before parents), or calculate directory storage sizes from the bottom up.

Binary Search Tree (BST)

A Binary Search Tree (BST) is a binary tree that maintains a strictly sorted structure:

  • The left subtree of a node contains ONLY values strictly less than the node's value.
  • The right subtree of a node contains ONLY values strictly greater than the node's value.
  • The left and right subtrees must themselves be valid BSTs.
       8
      / \
     3   10
    / \    \
   1   6    14

Because of this sorted structure, every time you make a decision to go left or right, you discard half of the remaining nodes. You can search, insert, or delete elements in $O(\log N)$ average time, identical to binary search in arrays.

The Danger of Unbalanced BSTs

If you insert pre-sorted data into a basic BST (e.g., [1, 2, 3, 4, 5]), the tree never branches left. It becomes a skewed, straight line that looks exactly like a Linked List. The search complexity degrades catastrophically to $O(N)$.

To prevent this, production systems (like database indexing algorithms) use Self-Balancing Trees (such as AVL Trees or Red-Black Trees). These trees automatically detect when a branch is getting too long and perform complex pointer rotations to keep the tree perfectly balanced at all times.

Advanced Tree Variations

1. The Trie (Prefix Tree)

A Trie is an incredibly efficient tree designed specifically for string manipulation and prefix matching. It is the underlying data structure used for:

  • Search engine autocomplete suggestions.
  • Spell checkers.
  • IP routing longest-prefix matching.

In a Trie, edges (or nodes) represent individual characters. The path from the root to a node spells out a word. Searching for a string of length $L$ takes $O(L)$ time, regardless of how many millions of words are stored in the dictionary!

2. The Binary Heap (Priority Queue)

A Binary Heap is a complete binary tree where the parent node is strictly greater than (Max-Heap) or strictly less than (Min-Heap) its children. It is used to implement Priority Queues and is the backbone of Dijkstra's Shortest Path Algorithm. Fascinatingly, because Heaps are strictly complete trees (filled left-to-right), they are usually implemented internally using a flat Array rather than Node objects with pointers, saving immense amounts of memory.

Complete BST Implementation (TypeScript)

Here is a full code reference for a Binary Search Tree, including insertion, search, and a recursive In-Order traversal:

class TreeNode {
  val: number;
  left: TreeNode | null = null;
  right: TreeNode | null = null;
  constructor(val: number) { this.val = val; }
}

class BinarySearchTree {
  private root: TreeNode | null = null;

  // Average: O(log N) | Worst: O(N)
  public insert(val: number): void {
    this.root = this.insertNode(this.root, val);
  }

  private insertNode(node: TreeNode | null, val: number): TreeNode {
    if (!node) return new TreeNode(val);

    if (val < node.val) {
      node.left = this.insertNode(node.left, val);
    } else {
      node.right = this.insertNode(node.right, val);
    }
    return node;
  }

  // Average: O(log N) | Worst: O(N)
  public search(val: number): boolean {
    return this.searchNode(this.root, val);
  }

  private searchNode(node: TreeNode | null, val: number): boolean {
    if (!node) return false;
    if (node.val === val) return true;

    return val < node.val
      ? this.searchNode(node.left, val)
      : this.searchNode(node.right, val);
  }

  // In-order traversal (Left -> Root -> Right)
  // Returns elements in sorted order!
  public traverseInOrder(node = this.root, result: number[] = []): number[] {
    if (node !== null) {
      this.traverseInOrder(node.left, result);
      result.push(node.val);
      this.traverseInOrder(node.right, result);
    }
    return result;
  }
}

For how recursion powers tree traversals under the hood, see recursion and backtracking.
