Graph Traversals: Node Exploration, Matrices, and Shortest Paths

Graphs are the most versatile data structure in computer science. They are used to model networks of connected elements: from friends on a social network and streets on Google Maps, to routers on the internet and dependencies in a package manager.

A graph consists of a set of Nodes (Vertices) connected by Links (Edges). Edges can be Directed (one-way streets) or Undirected (two-way streets), and they can carry a Weight (representing cost or distance).

---

Graph Representation: List vs. Matrix

How do we actually store a graph in code? There are two primary approaches, and choosing the wrong one will crash your system due to memory limits (Out of Memory errors).

1. Adjacency Matrix

A 2D array (Grid) where cell matrix[i][j] is 1 if there is an edge between vertex i and vertex j, and 0 otherwise.

   0  1  2
0  0  1  0
1  1  0  1
2  0  1  0

• Pros: Blazing fast $O(1)$ time to check if an edge exists between two nodes.
• Cons: Astronomical $O(V^2)$ memory usage. If you have 1 million users on a social network, an adjacency matrix requires $1,000,000 \times 1,000,000 = 1 \text$ cells, eating up Terabytes of RAM, even if each user only has 10 friends.

2. Adjacency List (The Standard)

An array of lists (or a Hash Map of Arrays) where index i stores a list of all vertices strictly connected to vertex i.

0: -> [ 1 ]
1: -> [ 0, 2 ]
2: -> [ 1 ]

• Pros: Highly space-efficient $O(V + E)$ memory usage. Perfect for "Sparse Graphs" (graphs where most nodes are NOT connected to most other nodes, which is 99% of real-world graphs).
• Cons: Slower edge checks ($O(V)$ in the worst case to iterate through a user's friend list to find a specific friend).

---

BFS vs. DFS: Exploring Graphs

To search a graph, you must traverse it without getting trapped in an infinite cycle.

Breadth-First Search (BFS)

BFS explores the graph level-by-level. It visits all immediate neighbors of a node (Level 1) before moving to their neighbors (Level 2).

• Underlying Structure: Uses a Queue (FIFO).
• Superpower: BFS is guaranteed to find the Shortest Path in an unweighted graph. It is the core algorithm behind solving mazes or finding degrees of separation.

graph TD
    A[Start Node] --> B[Visit Neighbors - Level 1]
    B --> C[Visit Neighbors - Level 2]
    C --> D[Visit Neighbors - Level 3]

Depth-First Search (DFS)

DFS acts like a rat in a maze: it explores a single branch as deeply as possible before backtracking.

• Underlying Structure: Uses a Stack (or Call Stack via Recursion).
• Superpower: DFS is incredibly memory efficient for deep graphs and is the required algorithm for Topological Sorting (ordering compilation dependencies) and detecting cycles.

graph TD
    A[Start Node] --> B[Go Deep along Branch 1]
    B --> C[Reach Dead End]
    C -->|Backtrack| D[Explore Branch 2]

---

Traverse Implementations (TypeScript)

Here is a full Object-Oriented class implementation demonstrating both BFS and DFS traversals on an adjacency list.

class Graph {
  // Using a Map for the Adjacency List
  private adjList: Map<number, number[]>;

  constructor() {
    this.adjList = new Map();
  }

  public addVertex(v: number): void {
    if (!this.adjList.has(v)) {
      this.adjList.set(v, []);
    }
  }

  public addEdge(v: number, w: number): void {
    this.addVertex(v);
    this.addVertex(w);
    // Undirected graph: add edge in both directions
    this.adjList.get(v)!.push(w);
    this.adjList.get(w)!.push(v);
  }

  // Breadth-First Search (using a Queue)
  public bfs(startNode: number): number[] {
    const visited = new Set<number>();
    const queue: number[] = [startNode];
    const result: number[] = [];

    visited.add(startNode);

    while (queue.length > 0) {
      const node = queue.shift()!; // Dequeue (Note: Use a real queue for O(1))
      result.push(node);

      const neighbors = this.adjList.get(node) || [];
      for (const neighbor of neighbors) {
        if (!visited.has(neighbor)) {
          visited.add(neighbor); // Mark visited IMMEDIATELY when queueing
          queue.push(neighbor);
        }
      }
    }
    return result;
  }

  // Depth-First Search (using Recursion / Call Stack)
  public dfs(startNode: number, visited = new Set<number>(), result: number[] = []): number[] {
    visited.add(startNode);
    result.push(startNode);

    const neighbors = this.adjList.get(startNode) || [];
    for (const neighbor of neighbors) {
      if (!visited.has(neighbor)) {
        this.dfs(neighbor, visited, result);
      }
    }
    return result;
  }
}

Advanced Algorithms

If your graph edges have varying weights (e.g., travel times on roads), BFS will fail to find the fastest route. In these scenarios, you must use Dijkstra's Algorithm, which replaces the standard FIFO Queue with a Priority Queue (Min-Heap) to prioritize exploring cheaper paths first.

For queue details, see queues. For stack details, see stacks.
