Hash Maps Under the Hood: Collisions, Chaining, and Resizing

Hash maps (or Hash Tables, Dictionaries) are the most heavily used data structure in software engineering. They store data in Key-Value pairs and support search, insertion, and deletion in $O(1)$ average time.

Whether you are caching database queries, counting word frequencies, or building a Two-Sum algorithm, Hash Maps are the go-to tool.

---

The Illusion of $O(1)$

Under the hood, a Hash Map is literally just an Array. Arrays offer $O(1)$ lookup, but only if you know the exact integer index. You cannot ask an array to get("userZ").

To bridge this gap, Hash Maps use a mathematical Hash Function to irreversibly scramble the Key into a massive integer, and then use the Modulo operator to map that integer to a valid Array index.

Index = HashFunction(Key) % Array_Capacity

Key: "userA" -> Hash: 432598 -> Index (Size 10): 8 -> Array[8] = Value

Cryptographic vs. Non-Cryptographic Hashes

• Cryptographic Hashes (SHA-256, MD5): Designed for security. They are intentionally slow to prevent brute-force attacks and ensure extreme avalanche effects (changing one letter changes the entire hash). They are never used for data structure Hash Maps.
• Non-Cryptographic Hashes (MurmurHash, CityHash): Designed for pure speed and uniform distribution. They can hash gigabytes of data per second. Language runtimes (like V8 or the JVM) use these to power their native Map or Dictionary objects.

---

Collision Resolution Mechanisms

The Pigeonhole Principle states that if you put 11 pigeons into 10 holes, at least one hole must contain two pigeons. Because the number of possible strings (Keys) is infinite, but the Hash Map array size is finite, collisions are mathematically guaranteed.

A collision occurs when two distinct keys hash to the exact same array index. Hash Maps handle this in one of two ways:

1. Separate Chaining (Linked Lists)

Each array index (Bucket) doesn't store a value directly; it stores a pointer to a Linked List. If multiple keys collide at Index 3, they are simply appended to the linked list at Index 3.

Array[3] -> [ Key: "userA" | Val: 10 ] -> [ Key: "userZ" | Val: 99 ] -> NULL

• Pros: Deletions are trivial. The map never "fills up" entirely.
• Cons: Pointer chasing destroys CPU cache locality, slowing down lookups.

2. Open Addressing (Linear Probing)

Used by modern, high-performance Hash Maps (like Python's dict). The array stores the values directly without Linked Lists. If a collision occurs, the hash map simply probes the next adjacent index in the array until it finds an empty slot.

Array[3] - occupied -> check Array[4] - empty -> store there!

• Pros: Fantastic cache locality. Extremely fast.
• Cons: Deletions are complex (requires "Tombstone" markers). Subject to clustering.

---

Load Factor and Array Resizing

The Load Factor (alpha) is the ratio of stored items to the array's capacity:

Load_Factor = Number_of_Items / Capacity

As the load factor increases, the array fills up, collisions skyrocket, and the $O(1)$ performance degrades into $O(N)$ as the algorithm searches through long chains or heavily clustered open-addressed blocks.

To prevent this, most hash maps resize their underlying array when the load factor exceeds a threshold (typically 0.75):

1. Allocate a completely new array with double the capacity.
2. Re-hash every single key from the old array, modulo it against the new capacity, and insert it into the new array.
3. Garbage collect the old array.

Resizing takes $O(N)$ time. However, because it happens exponentially less often as the array grows, insertions still maintain an $O(1)$ amortized time.

---

Custom Hash Map Implementation (TypeScript)

Here is a simplified hash map implementation demonstrating Separate Chaining:

class HashNode<K, V> {
  key: K;
  value: V;
  next: HashNode<K, V> | null = null;
  constructor(key: K, value: V) {
    this.key = key;
    this.value = value;
  }
}

class CustomHashMap<K, V> {
  private buckets: Array<HashNode<K, V> | null>;
  private capacity: number;
  private count: number;

  constructor(initialCapacity = 16) {
    this.capacity = initialCapacity;
    this.buckets = new Array(this.capacity).fill(null);
    this.count = 0;
  }

  // A basic string hashing algorithm (djb2 variant)
  private getHashIndex(key: K): number {
    const keyStr = String(key);
    let hash = 5381;
    for (let i = 0; i < keyStr.length; i++) {
      hash = (hash * 33) ^ keyStr.charCodeAt(i);
    }
    return Math.abs(hash) % this.capacity;
  }

  public put(key: K, value: V): void {
    const index = this.getHashIndex(key);
    let head = this.buckets[index];

    // Traverse the chain to check for existing key updates
    while (head !== null) {
      if (head.key === key) {
        head.value = value;
        return;
      }
      head = head.next;
    }

    // Insert new node at the front of the list for O(1) insertion
    const newNode = new HashNode(key, value);
    newNode.next = this.buckets[index];
    this.buckets[index] = newNode;
    this.count++;
  }

  public get(key: K): V | undefined {
    const index = this.getHashIndex(key);
    let head = this.buckets[index];

    // Traverse the chain to find the key
    while (head !== null) {
      if (head.key === key) {
        return head.value;
      }
      head = head.next;
    }
    return undefined; // Not found
  }
}

For memory details on array layouts, see arrays guide.
